Design-Based Research Capstone

NodCursor Capstone

A Research Through Design capstone for a browser-based, privacy-first head-tracking cursor controller that maps head motion and facial gestures to mouse events using MediaPipe — no cloud, no installs.

View Project

In Development / Testing

Project Leads Aadi Bhat, Pranav Santhosh

NodCursor

Head-Driven Cursor Control Without Installs or Cloud

✓ Browser-native head tracking via MediaPipe FaceLandmarker

✓ Facial gestures mapped to click, scroll, and drag events

✓ Web Worker pipeline for real-time smoothing with minimal latency

✓ Calibration system mapping head range to viewport coordinates

✓ Exponential smoothing with deadzone and acceleration curve

✓ Blink, double-blink, and long-blink gesture detection

✓ React + TypeScript + Vite, entirely client-side

✓ Privacy-first: no data leaves the browser

React + TypeScript + Vite MediaPipe Tasks Vision (FaceLandmarker) Web Worker (trackingWorker.ts) Exponential Smoothing Pipeline Tailwind CSS Calibration Viewport Mapping Gesture Dispatch (useGestureControls) useFaceTracking / useCursorMapping Hooks

About

NodCursor is a browser-based accessibility tool that replaces the mouse with head movement and facial gestures. Powered by MediaPipe Tasks Vision, it tracks facial landmarks in real time and maps nose position and brow tilt to cursor coordinates. A Web Worker handles exponential smoothing and gesture signal derivation off the main thread, keeping the UI fluid. A calibration flow lets users define their natural head range and snap it to the viewport. Gesture controls — blink, double-blink, long-blink — trigger click and scroll actions without any hardware beyond a webcam. Built with React, TypeScript, and Vite, the entire stack runs locally in the browser with no accounts, no server, and no data transmission.

Impact

Fully browser-native — no app install required

Privacy-first: all inference runs locally on-device

Accessible cursor control for motor-impaired users

Gesture-based click and scroll without physical peripherals

Smooth tracking across varied lighting and camera setups

Deadzone and acceleration tuning for fatigue-free use

Calibration system adapts to each user's motion range

Foundation for gaze, voice, and switch-access extensions
